Simple
Smarting
Reliable
Mobile

Wireless EEG device for high-quality recordings and monitoring brain activity in real-time. When paired with PC, SMARTING provides superior data quality with excellent time precision.

High signal quality
Submillisecond time precision
Easy to use streamer for PC
Real time raw data
A wireless EEG device for high quality recordings and monitoring brain activity in real time, outside the lab. When paired with a PC, Smarting provides superior data quality with an excellent time precision.

Smartfones compatible
Combine Smarting with our innovative EEG headgear, perfectly suitable for auditory and music studies. Explore SMARTFONES and check out our reference use cases
Explore Smartfones
Key features
-
Lighter than 60g
physical dimension 8x5 cm
-
250 – 500 Hz sampling rate
with 0-133Hz flat frequency response
-
24 Channel recording cap
24 bits with < 1µV input referred noise
-
Motion tracking
with 3D built in gyroscope
-
10M wireless range
using bluetooth 2.1 connection
-
Up to 5 hours recording
Wireless EEG data streaming
General
|
|
Name | Smarting mobi |
Number of channels | 24 |
Channel Type / Reference referential channels / |
Referential channels / recording with one electrode |
Input impedance | 1 GΩ |
Input Referred Noise | <1 µV |
Input Range | (-100)mV – 100 mV |
CMMR | > 140 dB* |
Gain | 24 |
Gyroscope | 3D Built-in |
*measured at 50Hz common mode | *measured at 50Hz common mode |
Connectors |
|
Electrode Connectors | IDC |
EEG Cap Layouts |
|
Standard | Motor |
Dimensions |
|
Physical box size | 82x51x12 mm |
Weight | <60 grams |
AD conversion |
|
Sampling frequency | 250 or 500 Hz |
Sampling | Parallel sampling |
Resolution | 24-bits |
Bandwidth | 0-250 Hz |
Flat Frequency | 0-133 Hz |
Response | (3dB attenuation at 133Hz), true DC performance |
Anti-aliasing Filter | YES |
Active Ground | YES |
Communication type |
|
Wireless Communications | Bluetooth range v2.1 + EDR |
Bluetooth range | ~10 meters |
Power |
|
Power Supply | USB Type-C |
Battery Type | Internal |
Operation time | ~ 5 hours |
How it works?
-
Mounting the EEG cap
Feb 2023 -
Checkerboard task
Feb 2023 -
Connecting to PC and streamer
Feb 2023
